TRANSPARENT SCREEN SERIES
Items Transparent Screen Series(Indoor) Transparent Screen Series(Outdoor) JS3.9 JS7.8 JS10.4 JS15.6 CT3.9 CT7.8 CT10.4 Pixel Pitch(mm) 3.9*7.8 7.8*7.8 10.4*10.4 15.6*15.6 3.96*7.81 7.81 10.4 Scan 1/4 1/4 1/2 Static 1/4 1/4 1/2 Pixel Density(Dots/㎡) 32768 16384 9216 4096 32256 16384 9216 Module Resolution(Dots) 16384 8192 4608 2048 4032 2048 1152 Brightness(cd/㎡) 5500 6500 4500 Transparency >... -
FIXED CABINET
Items DA-I(Indoor) MG-O(Outdoor) Q/S1.2 Q/S1.5 Q/S1.6 Q/S1.8 Q/S2 Q/S2.5 Q/S3.0 Q/S4 Q/S2 Q/S2.5 Q/S3.0 Q/S4 Q/S5 Q/S6.66 Q/S8 Q/S10 Scan 1/32 1/26 1/32 1/43 1/40 1/32 1/26 1/20 1/20 1/16 1/13 1/10 1/8 1/6 1/5 1/2 Module(W*H) 2*3 3*6 Module Size(mm) 320*160 320*160 Supply Voltage(v) 4.5V 4.5V Cabinet Area (sqm) 0.3072㎡ 0.9216㎡ Cabinet Weight 3.70Kg (Cabinet Frame Only), 7.8Kg (Complete Set Cabinet) 12.9kg (Cabinet Frame Only)/29.7kg (Compl... -
KLRENTAL SERIES
Items KL Rental Series(Indoor) KL Rental Series(Outdoor) KL-J-S KL-J-H Match Pixel Pitch Module Size(mm) 1.6 1.8 2 2.5 3.0 4 2.5 3.0 4 5 6.6 8 10 Scan 1/32 1/43 1/40 1/32 1/26 1/20 1/16 1/13 1/10 1/8 1/6 1/5 1/2 Moudle (W*H) 2*3 2*3 Cabinet Size(mm) 640*480 640*480 Cabinet Frame Material Aluminium Alloy Aluminium Alloy Cabinet Weight (kg) 10.33 10.75 Cabine... -
INDOOR QM CABINET SERIES
Items QM-Pro-08 QM-Pro-0 QM-Pro-1 QM-Pro-2 QM-E Match Pixel Pitch Module Size(mm) 0.8 1 1.2 1.3 1.5 1.6 1.5 1.8 2 2.5 3.0 4 1.5 1.6 1.8 2 2.5 3.0 4 Scan 1/45 1/40 1/32 1/29 1/26 1/32 1/52 1/43 1/40 1/32 1/26 1/20 1/52 1/32 1/43 1/40 1/32 1/26 1/20 Moudle (W*H) 2*3 Cabinet Size(mm) 640*480 Cabinet Frame Material Aluminium Alloy Cabinet Weight( kg) 5 5 5 5 3.2(Fram... -
CORNER LED MODULE SERIES
Outdoor Single Color (Red) 01 The new 4-sided beveled bottom base design module can easily create the outer arc screen, right-angle screen and multi-faceted screen which realize easily the real naked eye 3D effect. Beveled bottom base base module adopts one-piece structure d... -
FLEXIBLE MODULE SERIES
Items Flexible Module H-R(Indoor) Flexible Module Pro-R(Indoor) Q1.5H-R Q1.8H-R Q2.0H-R Q2.5H-R Q1.5Pro-R Q1.8Pro-R Q2.0Pro-R Q2.5Pro-R Pixel Pitch(mm) 1.5 1.8 2.0 2.5 1.5 1.8 2.0 2.5 Scan 1/52 1/43 1/40 1/64 1/52 1/43 1/40 1/64 Module Size(mm) 320*160 Module Resolution(Dots) 208*104 172*86 160*80 128*64 208*104 172*86 160*80 128*64 Pixel Density(Dots/㎡) 422500 288906 250000 160000 422500 288906 250000 160000 Energy Consumption Level Grade 1 ... -
DM SERIES
Items DM Series(Indoor) DM Series(Outdoor) P3.9-E P2.6-Pro P3.9-Pro P3.9-Pro P4.8-Pro Pixel Pitch(mm) 3.9 2.6 3.9 3.9 4.8 Scan 1/16 1/24 1/16 1/16 1/13 Module Size(mm) 250*250 250*250 Module Resolution(Dots) 64*64 96*96 64*64 64*64 52*52 Pixel Density(Dots/㎡) 65536 147456 65536 65536 43264 Energy Consumption Level Grade 1 Grade 1 Supply Voltage(v) ≥4.5 ≥4.5 Brightness(cd/㎡) 500-600 600-700 4000-5000 Color Temperature(k) 6500~18000 Adj... -
SINGLE COLOR SERIES
Items Single Color Series(Outdoor) P10 Pixel Pitch(mm) 10 Scan 1/4 Module Size(mm) 320*160 Module Resolution(Dots) 32*16=512Dots Pixel Density(Dots/㎡) 10000 Energy Consumption Level Grade 1 Supply Voltage(v) 4.5V Brightness(cd/㎡) 800 Color Temperature(k) 6500~18000 Adjustable Contrast ≥5000：1 Driving IC Current Driving IC Gray Scale (Bit) 8 Refresh Rate(Hz) 960 Maximum Power Consumption(W/㎡) 308W Average Power Consumptio... -
OUTDOOR FULL COLOR Q-PRO/E SERIES
Items Q-Pro Series(Outdoor) Q-E Series(Outdoor) Q2.5 Q3.0 Q4 Q5 Q6 Q6.6 Q8 Q10 Q2.5 Q3.0 Q4 Q5 Q6 Q6.6 Q8 Q10 Pixel Pitch(mm) 2.5 3.0 4 5 6 6.6 8 10 2.5 3.0 4 5 6 6.6 8 10 Scan 1/16 1/13 1/10 1/8 1/8 1/6 1/5 1/2 1/16 1/13 1/10 1/8 1/8 1/6 1/5 1/2 Module Size(mm) 320*160 192*192 320*160 320*160 192*192 320*160 Module Resolution(Dots) 128*64 104*52 80*40 64*32 32*32 48*24 40*20 32*16 128*64 104*52 80*40 64*32 32*32 48*24 40*20 32*16 Pixel Density(Dots/... -
OUTDOOR FULL COLOR S SERIES
Items S Series(Outdoor) S2 S2.5 S3.0 S4 S5 S6.6 S8 S10 Pixel Pitch(mm) 2 2.5 3.0 4 5 6.6 8 10 Scan 1/20 1/16 1/13 1/10 1/8 1/6 1/5 1/2 Module Size(mm) 320*160 Module Resolution(Dots) 160*80 128*64 104*52 80*40 64*32 48*24 40*20 32*16 Pixel Density(Dots/㎡) 250000 160000 105625 62500 40000 22500 15625 10000 Energy Consumption Level Grade 1 Supply Voltage(v) ≥4.5 Brightness(cd/㎡) 5500-6000 5500-7000 Color Temperature(k) 6500~18000 Adjustable ... -
INDOOR FULL COLOR Q-H/E SERIES
[ Product Model]
-
INDOOR FULL COLOR Q-PRO SERIES
Items Q-Pro Series(Indoor) Q0.8 Q1 Q1.2 Q1.3 Q1.5 Q1.6 Q1.8 Q2 Q2.5 Q3 Q3.0 Q4 Pixel Pitch(mm) 0.8 1 1.2 1.3 1.5 1.6 1.8 2 2.5 3 3.0 4 Scan 1/45 1/40 1/64 1/29 1/52 1/32 1/43 1/40 1/32 1/32 1/26 1/20 Module Size(mm) 320*160 192*192 320*160 Module Resolution(Dots) 360*180 320*160 256*128 232*116 208*104 192*96 172*86 160*80 128*64 64*64 104*52 80*40 Pixel Density(Dots/㎡) 1265625 1000000 640000 525625 422500 360000 288906 250000 160000 111111 105625 6...
